| Processor |
AMD Ryzen™ 7 7730U (8C / 16T, 2.0 / 4.5GHz, 4MB L2 / 16MB L3)
|
| Graphics |
Integrated AMD Radeon™ Graphics
|
| Chipset |
AMD SoC Platform
|
| Memory |
16GB Soldered LPDDR4x-4266
|
| Memory Slots |
Memory soldered to systemboard, no slots, dual-channel
|
| Max Memory |
16GB soldered memory, not upgradable
|
| Storage |
512GB SSD M.2 2242 PCIe® 4.0x4 NVMe®
|
| Storage Support
|
One drive, up to 1TB M.2 2242 SSD
|
| Storage Slot |
One M.2 2242 PCIe® 3.0 x4 slot
|
| Card Reader |
microSD Card Reader
|
| Optical |
None
|
| Audio Chip |
High Definition (HD) Audio, Realtek® ALC3287 codec
|
| Speakers |
Stereo speakers, 2W x2, optimized with Dolby® Atmos®
|
| Camera |
FHD 1080p + IR with Privacy Shutter
|
| Microphone |
2x, Array
|
| Battery
|
Integrated 59Wh
|
| Power Adapter |
45W USB-C® (3-pin)
|
| DESIGN |
| Display
|
13.3" WUXGA (1920 x 1200) IPS 300nits Glossy, 100% sRGB, Dolby® Vision™, TÜV Low Blue Light, Touch
|
| Touchscreen |
OGM, 10-point Multi-touch
|
| Keyboard |
Backlit, English
|
| Case Color |
Dark Teal
|
| Surface Treatment |
Fabric
|
| Case Material |
Fabric + Aluminium (Top), PC-ABS (Bottom)
|
| Pen |
Lenovo® Digital Pen
|
| Dimensions (WxDxH)
|
304 x 218 x 17.36 mm (11.97 x 8.58 x 0.68 inches)
|
| Weight
|
Starting at 1.39 kg (3.06 lbs)
|
| SOFTWARE |
| Operating System |
Windows® 11 Home Single Language, English
|
| Bundled Software |
Office Home & Student 2021
|
| CONNECTIVITY |
| Ethernet |
No Onboard Ethernet
|
| WLAN + Bluetooth
|
Wi-Fi® 6, 11ax 2x2 + BT5.1
|
| WWAN |
None
|
| NFC |
None
|
| Standard Ports |
- 2x USB-C® 5Gbps (USB-C 3.2 Gen 1), with Power Delivery 3.0 and DisplayPort™ 1.4
- 1x USB-A 5Gbps (USB 3.2 Gen 1)
- 1x USB-A 5Gbps (USB 3.2 Gen 1), Always On
- 1x HDMI® 2.1, up to 4K/60Hz
- 1x microSD card reader
- 1x Headphone / microphone combo jack (3.5mm)
|
| Docking |
Various docking solutions are supported via USB-C®. For more compatible docking solutions, please visit Docking for Yoga® 6 13ABR8
|
| Monitor Cable |
None
|
| Security Chip |
Firmware TPM 2.0
|
| Fingerprint Reader |
Touch Style, on Palm Rest
|
| Other Security |
- Camera privacy shutter
- IR camera for Windows® Hello
|
| SERVICE |
| Base Warranty |
1-year, Courier or Carry-in
|
| Included Upgrade |
3Y Premium Care -IPPREM (ESS)
|
| ACCESSORIES |
| Bundled Accessories |
None
|
| CERTIFICATIONS |
| Green Certifications
|
- ENERGY STAR® 8.0
- EPEAT™ Gold Registered
- ErP Lot 6
- ErP Lot 26
- RoHS compliant
|
| Other Certifications |
TÜV Rheinland® Low Blue Light (Software Solution)
|
| Mil-Spec Test |
MIL-STD-810H military test passed
|
