| Processor |
Intel® Core™ i7-13650HX, 14C (6P + 8E) / 20T, P-core 2.6 / 4.9GHz, E-core 1.9 / 3.6GHz, 24MB
|
| AI PC Category |
AI-Powered Gaming PC
|
| Graphics |
NVIDIA® GeForce RTX™ 4060 8GB GDDR6, Boost Clock 2370MHz, TGP 140W, 233 AI TOPS
|
| Chipset |
Intel® HM770 Chipset
|
| Memory |
2x 12GB SO-DIMM DDR5-4800
|
| Memory Slots |
Two DDR5 SO-DIMM slots, dual-channel capable
|
| Max Memory
|
Up to 24GB DDR5-4800 offering
|
| Storage |
1TB SSD M.2 2242 PCIe® 4.0x4 NVMe®
|
| Storage Support
|
Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB each
|
| Storage Slot |
Two M.2 2280 PCIe® 4.0 x4 slots
|
| Card Reader |
None
|
| Optical |
None
|
| Audio Chip |
High Definition (HD) Audio, Realtek® ALC3287 codec
|
| Speakers |
Stereo speakers, 2W x2, optimized with Nahimic Audio
|
| Camera |
HD 720p with E-shutter
|
| Microphone |
2x, Array
|
| Battery |
Integrated 60Wh
|
| Power Adapter |
230W Slim Tip (3-pin)
|
| DESIGN |
| Display |
15.6" FHD (1920x1080) IPS 300nits Anti-glare, 100% sRGB, 144Hz, G-SYNC®
|
| Touchscreen |
None
|
| Color Calibration |
None
|
| Keyboard |
White Backlit, English
|
| Touchpad |
Buttonless Mylar® surface multi-touch touchpad, 75 x 120 mm (2.95 x 4.72 inches)
|
| Case Color |
Storm Grey
|
| Surface Treatment |
Anodizing
|
| Case Material |
Aluminium (Top), PC-ABS (Bottom)
|
| Pen |
Pen Not Supported
|
| Dimensions (WxDxH)
|
358.8 x 261.4 x 20.5-24.65 mm (14.13 x 10.29 x 0.81-0.97 inches)
|
| Weight
|
Starting at 2.32 kg (5.12 lbs)
|
| SOFTWARE |
| Operating System |
Windows® 11 Home Single Language, English
|
| Bundled Software |
Office Home & Student 2021
|
| CONNECTIVITY |
| Ethernet |
100/1000M (RJ-45)
|
| WLAN + Bluetooth |
Wi-Fi® 6, 802.11ax 2x2 + BT5.2
|
| WWAN |
Non-WWAN
|
| Standard Ports |
- 2x USB-A (USB 5Gbps / USB 3.2 Gen 1)
- 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
- 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with Lenovo® PD 140W and DisplayPort™ 1.4
- 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with DisplayPort™ 1.4
- 1x HDMI® 2.1, up to 8K/60Hz
- 1x Headphone / microphone combo jack (3.5mm)
- 1x Ethernet (RJ-45)
- 1x Power connector
|
| Docking |
|
| SECURITY & PRIVACY |
| Security Chip |
Firmware TPM 2.0 Enabled
|
| Fingerprint Reader |
None
|
| Other Security |
E-shutter
|
| SERVICE |
| Base Warranty |
1-year, Courier or Carry-in
|
| Included Upgrade |
3Y Legion Ultimate Support -IPMAIN (ESS)
|
| ACCESSORIES |
| Bundled Accessories |
None
|
| CERTIFICATIONS |
| Green Certifications |
RoHS compliant
|
