| Print Head / Ink |
Type |
FINE Cartridge |
| Number of Nozzles |
Total 1,280 nozzles |
| Ink Cartridges |
PG-745S, CL-746S (Optional: PG-745, CL-746 / PG-745XL, CL-746XL) |
| Maximum Printing Resolution |
4800 (horizontal)*2 x 1200 (vertical) dpi |
Print Speed
Based on ISO / IEC 24734.
|
Document: Col |
ESAT / Simplex: Approx. 4.0 ipm |
| Document: B/W |
ESAT / Simplex: Approx. 7.7 ipm |
| Photo (4 x 6") |
PP-201 / Borderless: Approx. 65 sec |
| Printable Width |
Up to 203.2 mm (8 inch) |
| Printable Area |
Borderless Printing*3
|
Top / Bottom / Right / Left margin: each 0 mm
(Supported Paper Size: 4 x 6") |
| Bordered Printing |
Top margin: 3 mm, Bottom margin: 5 mm,
Left / Right margin: each 3.4 mm (LTR: Left: 6.4 mm, Right: 6.3 mm) |
| Recommended Printing Area |
Top margin: 31.6 mm / Bottom margin: 29.2 mm |
| Paper Size |
A4, LTR, 4 x 6", 5 x 7", Custom size (width 89 - 215.9 mm, length 127 - 676 mm)
* F4 is possible via custom size settings.
|
Paper Handling
(Rear Tray)
(Maximum Number) |
Plain Paper |
A4, LTR = 60 |
Photo Paper Plus Glossy II
(PP-201) |
4 x 6" = 20 |
Glossy Photo Paper "Everyday Use"
(GP-508) |
4 x 6" = 20 |
Photo Paper Plus Glossy II
(PP-208) |
4 x 6" = 20 |
Photo Sticker (Free cutting)
(PS-208) |
4 x 6" = 1 |
Photo Sticker (Free cutting, Removable)
(PS-308R) |
4 x 6" = 1 |
| Rear Tray |
Plain Paper: 64 - 105 g/m², Canon specialty paper: max paper weight: approx. 275 g/m²(Photo Paper Plus Glossy II (PP-201)) |
| Ink End Sensor |
Dot count |
| Print Head Alignment |
Manual |
|
|
(Please visit www.canon-asia.com to confirm OS compatibility and to download the latest driver updates) |
Windows: |
Windows 10, Windows 8.1, Windows 7 SP1 |
| Macintosh: |
Mac OS X 10.10.5 ~ 10.11, Mac OS 10.12*
* via AirPrint |
|
|
| Interface |
USB 2.0 Hi-Speed |
| Operating Environment*4
|
Temperature: |
5 - 35°C |
| Humidity: |
10 - 90% RH (no dew condensation) |
| Recommended Environment*5
|
Temperature: |
15 -30°C |
| Humidity: |
10 - 80% RH (no dew condensation) |
| Storage Environment |
Temperature: |
0 - 40°C |
| Humidity: |
5 - 95% RH(no dew condensation) |
| Quiet Mode |
Available |
| Acoustic Noise (PC Print) |
Photo (4 x 6")*6
|
Approx. 46.0 dB(A) |
| Power |
AC 100 - 240 V, 50/60 Hz |
| Power Consumption |
OFF |
Approx. 0.2 W |
Standby (scanning lamp is off)
(USB Connection to PC) |
Approx. 1.2 W |
| Standby (all ports connected, scanning lamp is off) |
Approx. 0.9 W |
| Printing*7
|
Approx. 10 W |
| Environment |
Regulation |
RoHS (EU, China), WEEE (EU) |
| Dimension (W x D x H) |
Factory configuration
|
426 x 255 x 131 mm |
| Output / ADF trays extended |
426 x 562 x 213 mm |
| Weight |
2.5 kg |
