Print Head / Consumables |
|
Number of Nozzles |
Total: 5,120 nozzles |
Ink Cartridges (Type/Colours) |
PG-750 (Pigment Ink / Black) |
|
CLI-751 (Dye-Based Ink / Cyan, Magenta, Yellow, Black) |
Optional Cartridges |
PGI-755XXL (Pigment Ink / Black) |
|
PGI-750XL PGBK (Pigment Ink / Black) |
|
CLI-751XL (Dye-Based Ink / Cyan, Magenta, Yellow, Black) |
Maximum Print Resolution |
9,600 (horizontal) × 2,400 (vertical) dpi |
Print Speed (Approx.) |
|
Document (ESAT/Simplex) |
14.5 ipm (mono) / 10.4 ipm (colour) |
Photo (11 × 14") (PP-201) |
120 sec |
Photo (4 × 6") (PP-201, Borderless) |
36 sec |
Print Width |
Up to 322.2 mm (12.7") |
|
Borderless: Up to 329 mm (13") |
Recommended Printing Area |
|
Top Margin |
40.7 mm |
Bottom Margin |
37.4 mm |
Paper Handling |
|
Print Margin |
|
Borderless Printing |
Top/Bottom/Left/Right: 0 mm |
Bordered Printing |
LTR, LGL: Top: 3 mm, Bottom: 5 mm, Left: 6.4 mm, Right: 6.3 mm |
|
Others: Top: 3 mm, Bottom: 5 mm, Left/Right: 3.4 mm |
Supported Media (Rear Tray) |
Plain Paper (64 - 105 g/m²) |
|
High Resolution Paper (HR-101N) |
|
Photo Paper Pro Platinum (PT-101) |
|
Photo Paper Pro Luster (LU-101) |
|
Photo Paper Plus Glossy II (PP-201) |
|
Photo Paper Plus Semi-Gloss (SG-201) |
|
Matte Photo Paper (MP-101) |
|
Envelope |
Paper Size (Rear Tray) |
A3+, A3, A4, A5, B4, B5, LTR, LGL, LDR |
|
Envelope (COM10, DL) |
|
4 × 6", 5 × 7", 8 × 10", 10 × 12" |
Custom Size |
Width: 55 - 329 mm |
|
Length: 91 - 676 mm |
|
(F4 possible via custom size settings) |
Borderless Printing |
A3+, A3, A4, LTR, LDR, 4 × 6", 5 × 7", 8 × 10", 10 × 12" |
Maximum Capacity (Rear Tray) |
|
Plain Paper (64 g/m²) |
A3, A4, A5, B4, B5, LTR, LGL, LDR: 150 sheets |
High Resolution Paper |
(HR-101N) A3+/A3/A4: 20/50/80 sheets |
Photo Paper Pro Platinum |
(PT-101) A3+/A3/A4/4 × 6": 1/10/10/20 sheets |
Photo Paper Pro Luster |
(LU-101) A3+/A3/A4: 1/10/10 sheets |
Photo Paper Plus Glossy II |
(PP-201) A3+/A3/A4/4 × 6": 1/10/10/20 sheets |
Photo Paper Plus Semi-Gloss |
(SG-201) A3+/A3/A4/8 × 10/4 × 6": 1/10/10/10/20 sheets |
Matte Photo Paper |
(MP-101) A3/A4/4 × 6": 10/10/20 sheets |
Envelope |
(COM10, DL): 10 sheets |
Paper Weight (Front Tray) |
Plain Paper: 64 - 105 g/m² |
|
Canon Paper: Approx. 300 g/m² (Max.) |
|
(Photo Paper Pro Platinum, PT-101) |
Printing Solutions |
Canon Printing Apps |
Other Software |
Easy-PhotoPrint Editor, Easy Layout Editor |
System Requirements |
|
OS Compatibility |
Windows 8 / 7 / XP / Vista |
|
macOS X 10.6.8 or later |
General Specifications |
|
Interface |
USB 2.0 |
Operating Environment |
|
Temperature |
5 - 35°C |
Humidity |
10 - 90% RH (no dew condensation) |
Recommended Environment |
|
Temperature |
15 - 30°C |
Humidity |
10 - 80% RH (no dew condensation) |
Storage Environment |
|
Temperature |
0 - 40°C |
Humidity |
5 - 95% RH (no dew condensation) |
Quiet Mode |
Available |
Acoustic Noise |
Photo (4 × 6"): 44.5 dB(A) |
Power Requirements |
AC 100 - 240 V, 50/60 Hz |
Power Consumption (Approx.) |
|
OFF |
0.2 W |
Standby |
0.8 W |
Operation |
21 W |
Dimensions (W × D × H) |
Factory Configuration: 584 × 310 × 159 mm |
Weight |
8.1 kg |
Page Yield (Plain Paper) |
|
A4 Colour Documents |
PGI-750 PGBK: 300 sheets |
|
CLI-751 BK: 1645 sheets |
|
CLI-751 C, M, Y: 334 sheets |
Optional Cartridges |
|
PGI-750XL PGBK |
500 sheets |
PGI-755XXL PGBK |
800 sheets |
CLI-751XL BK |
5000 sheets |
CLI-751XL C, M, Y |
690 sheets |
Page Yield (Photo Paper) |
|
4 × 6" Photos |
PGI-750 PGBK: 2390 photos |
|
CLI-751 BK: 384 photos |
|
CLI-751 C, M, Y: 128 photos |
Optional Cartridges |
|
PGI-750XL PGBK |
4720 photos |
PGI-755XXL PGBK |
7685 photos |
CLI-751XL BK |
845 photos |
CLI-751XL C, M, Y |
305 photos |
