Description
| Quick Specs: | • Processor - AMD Ryzen™ 5 3550H Mobile Processor • Graphics - AMD Radeon™ RX 560X • Memory - 4GB DDR4-2400 SO-DIMM • Storage - 1TB 5400RPM 2.5" SATA HDD • Resolution - FHD (1920 x 1080) 16:9 • Panel size - 15.6-inch • Battery - 48WHrs, 3S1P, 3-cell Li-ion |
||
Full Specs:
| Part No | 90NR01A1-M02910 |
| Model Name | FX505DY-AL080T |
| EAN Code | 4718017274272 |
| UPC Code | 192876274279 |
| Marketing Name | ASUS TUF Gaming |
| Color | Gold Steel |
| Dimension (W x D x H) | 36.0 x 26.2 x 2.58 ~ 2.68 cm |
| Weight | 2.20 Kg |
| Processor | AMD Ryzen™ 5 3550H Mobile Processor (4-core/8-thread, 6MB cache, 3.7 GHz max boost) |
| Chipset | N/A |
| Discrete/Optimus | Discrete |
| Graphic | AMD® Radeon™ RX 560X |
| Graphic Memory | 4GB GDDR5 |
| IGPU | AMD VEGA Graphics |
| Panel Size | 15.6-inch |
| Resolution | FHD (1920 x 1080) 16:9 |
| Refresh Rate | 120Hz |
| Viewing Angle | 85/85/85/85 |
| Panel Tech | Value IPS-level |
| Brightness | 250 |
| Contrast | 1000:1 |
| NTSC % | 45% |
| SRGB % | 62.5% |
| Adobe % | 47.10% |
| Anti glare | anti-glare display |
| Adaptive-Sync technology | N/A |
| Pantone | N/A |
| Total System Memory | 4GB DDR4-2400 SO-DIMM |
| On board memory | N/A |
| Memory Slot | 2x SO-DIMM slots |
| DIMM Memory | 4GB DDR4-2400 SO-DIMM |
| Memory Max. | 32GB |
| System Storage Installed | 1TB 5400RPM 2.5" SATA HDD |
| M.2 slots support either SATA or NVMe | 1 |
| M.2 SSD Support List | M.2 128GB PCIe M.2 256GB PCIe |
| LAN | 10/100/1000 Mbps |
| Wi-Fi/Bluetooth | Wi-Fi 5 (802.11ac) 1*1 + Bluetooth |
| I/O Ports | 1x USB 2.0 Type-A 2x USB 3.2 Gen 1 Type-A |
| Display output | 1x HDMI 2.0 |
| Audio | 1x 3.5mm Combo Audio Jack |
| Webcam | 720P HD camera |
| Mic | Built-in array microphone |
| Keyboard Type | Backlit Chiclet Keyboard 1-Zone RGB |
| NumberPad | N/A |
| Aura Sync | N/A |
| Speakers | 2-speaker system |
| Audio Tech | DTS software |
| Operating System | Windows 10 Home - ASUS recommends Windows 11 Pro for business |
| Security | Kensington Security Slot™ |
| Battery | 48WHrs, 3S1P, 3-cell Li-ion |
| Power | ø6.0, 120W AC Adapter, Output: 19V DC, 6.3A, 120W Input: 100-240V AC, 50/60Hz universal |
| Reparability Index (for FR) | 5.2 |
