Description
Key Features
- ATX Form Factor
- Intel B150 Chipset
- Intel LGA 1151 Socket
- 4 x Dual-Chanel DDR4-2133
- 6 x SATA III Ports, 1 x M.2 Socket 3
- 2 x PCIe 3.0/2.0 x16
- 1 x PCIe 3.0/2.0 x1 & 2 x PCI
- SupremeFX 8-Channel HD Codec
- Intel I219V Gigabit LAN Controller
- USB 3.1 Type-A & Type-C & USB 3.0/2.0
Full Specs:
| CPU |
- Intel Socket 1151 for 6th Generation Core i7/Core i5/Core i3/Pentium/Celeron Processors
- Supports Intel 14 nm CPU - Supports Intel Turbo Boost Technology 2.0 |
| Chipset |
Intel B150
|
| Memory |
- 4 x DIMM, Max. 64 GB, DDR4 2133 MHz Non-ECC, Un-buffered Memory
- Dual Channel Memory Architecture - Supports Intel Extreme Memory Profile (XMP) |
| Graphics |
Integrated Graphics Processor - Intel HD Graphics support
Multi-VGA output support: HDMI/RGB ports - Supports HDMI with a max resolution of 4096 x 2160 @ 24 Hz - Supports RGB with a max resolution of 1920 x 1200 @ 60 Hz Maximum shared memory of 1,024 MB Supports Intel InTru 3D, Quick Sync Video, Clear Video HD Technology, Insider Supports up to 3 displays simultaneously |
| Multi-GPU Support |
Supports AMD Quad-GPU CrossFireX Technology
Supports AMD 2-Way CrossFireX Technology |
| Expansion Slots |
1 x PCIe 3.0/2.0 x16 (x16 mode, gray)
1 x PCIe 3.0/2.0 x16 (max at x4 mode) 2 x PCIe 3.0/2.0 x1 2 x PCI When PCIE x16_2 is occupied by x4 or faster devices, PCIE x1_1 and PCIE x1_2 will be disabled |
| Storage |
Intel B150 Chipset:
1 x M.2 Socket 3, with M Key design, type 2242/2260/2280/22110 storage devices support (supports both SATA & PCIe SSD) 6 x SATA III 6 Gb/s ports When the M.2 Socket 3 is operating in SATA mode, SATA port 1 will be disabled |
| LAN |
Intel I219V, 1 x Gigabit LAN Controller, GameFirst technology
Anti-surge LANGuard |
| Audio |
SupremeFX 8-Channel High Definition Audio CODEC
- Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking - High quality 115 dB SNR stereo playback output Audio Features: - SupremeFX Shielding Technology - Optical S/PDIF out port at back panel - Sonic Radar II |
| USB Ports |
ASMedia USB 3.1 Controller:
1 x USB 3.1 port (Type-A) ASMedia USB 3.1 Controller: 1 x USB 3.1 port (Type-C, Reversible) Intel B150 Chipset: 6 x USB 3.0/2.0 ports (4 at the back panel, 2 at mid-board) Intel B150 chipset: 6 x USB 2.0/1.1 ports (2 at the back panel, 4 at mid-board) |
| Special Features |
Gamer's Guardian:
- ESD Guards on LAN, Audio, KBMS and USB3.0/2.0 ports - DRAM Overcurrent Protection - Stainless Steel Back I/O - Highly Durable Components - DIGI+ VRM ASUS EPU: - EPU ASUS Exclusive Features: - AI Suite 3 - Ai Charger+ - ASUS UEFI BIOS EZ Mode featuring a friendly graphics user interface - USB 3.1 Boost - Disk Unlocker ASUS Quiet Thermal Solution: - Fanless Design Heat-sink solution & MOS Heatsink - ASUS Fan Xpert 3 ASUS EZ DIY: - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode - Push Notice ASUS Q-Design: - ASUS Q-Shield - ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED) - ASUS Q-Slot - ASUS Q-DIMM Media Streamer RAMCache |
| Compatible Operating Systems |
Windows 10, 64-bit
Windows 8.1, 64-bit Windows 7, 32/64-bit |
| Back I/O Ports |
1 x PS/2 keyboard/mouse combo port
1 x D-Sub 1 x HDMI 1 x LAN (RJ-45) port 1 x USB 3.1 Type-A (red) 1 x USB 3.1 Type-C 4 x USB 3.0 2 x USB 2.0 1 x Optical S/PDIF out 5 x Audio jacks |
| Internal I/O Ports |
1 x USB 3.0 connector supports an additional 2 USB 3.0 ports (19-pin)
2 x USB 2.0 connectors support an additional 4 USB 2.0 ports 1 x M.2 Socket 3 with M Key design, type 2242/2260/2280/22110 storage devices support (supports both SATA & PCIe SSDs) 1 x COM port connector 6 x SATA III 6 Gb/s connectors 1 x CPU Fan connector (1 x 4-pin) 3 x Chassis Fan connectors (3 x 4-pin) 1 x 24-pin EATX Power connector 1 x 8-pin ATX 12 V Power connector 1 x Front panel audio connector (AAFP) 1 x System panel 1 x Thermal sensor connector 1 x CPU OV 1 x Clear CMOS jumper 1 x Water Pump header (4-pin) 1 x ROG extension (ROG_EXT) header 1 x 14-1 pin TPM connector |
| BIOS |
128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 3.0, WfM 2.0, SM BIOS 3.0, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F6 Qfan Control, F3 My Favorites, F9 Quick Note, Last Modified Log, F12 PrintScreen function, and ASUS DRAM SPD (Serial Presence Detect) memory information
|
| Manageability |
WfM 2.0, DMI 3.0, WOL by PME, PXE
|
| Support Disc |
Drivers
ASUS Utilities ASUS EZ Update Anti-virus software (OEM version) |
| Form Factor |
ATX Form Factor
12.6 x 9.6" / 32.0 x 24.4 cm |
Packaging Info
| Package Weight |
3.05 lb
|
| Box Dimensions (LxWxH) |
13 x 10.5 x 2.7"
|
